■ Crusher Hammer High Manganese Material:
Mn13Cr2,Mn18Cr2;
■ Crusher Hammer High Chromium Cast Iron:
Cr13Mo,Cr16Mo,Cr20Mo;
■ Crusher Hammer weight range:
10-100kg;
■ High Manganese Stell Grate Manufacturing process flow:
process design, model making, casting, water toughening heat treatment, machining, packaging;
■ Casting Process:
Casting accuracy is CT12, alkaline phenolic resin sand modeling, molten steel is refined;
■ Crusher Hammer Microstructure：
Austenite + Carbide; Martensite + C3Cr7;
■ Product Testing:
body hardness testing, proportional NDT, mechanical performance testing of samples, metallographic testing of samples;
■ Packing:
steel bracket.
